SD1209T5-A1
Manufacturer:
TDK Corporation
Mfr.Part #:
SD1209T5-A1
Datasheet:
Description:
Buzzers/Loudspeaker Through Hole 80 dB 2.048 kHz 12 mm x 9 mm
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 5 V |
| Termination | PC Pin |
| Diameter | 12 mm |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Resistance | 90 Ω |
| Height | 9 mm |
| Packaging | Reel |
| Voltage Rating | 5 V |
| Lead Free | Lead Free |
| RoHS | Compliant |
| Impedance | 90 Ω |
| Frequency | 2.048 kHz |
| Self Resonant Frequency | 2.05 kHz |
| Type | Electromagnetic Buzzer |
| Number of Terminals | 2 |
| Current | 60 mA |
| Current Rating | 60 mA |
| Operating Supply Voltage | 5 V |
| Lifecycle Status | Production (Last Updated: 1 year ago) |
| Max Supply Voltage | 6 V |
| Min Supply Voltage | 3 V |
| Operating Supply Current | 60 mA |
| Max Supply Current | 60 mA |
| Shape | Cylinder |
| Sensing Method | Magnetic |
| Washable | No |
| Schedule B | 8531800040 |
| Dimensions | 12 mm x 9 mm |
| Sound Pressure Level | 80 dB |
| Tone | Continuous |
